Day/Night Zoom Camera (Art. no. TVCC51000)

Special product features:

  • 600 TVL resolution
  • 36 x autofocus lens, 3.4 mm - 122.4 mm
  • 1/4" Sony Exview HAD II CCD
  • Day/night camera with swivelling IR cut filter (ICR)
  • Automatic focusing for images that are always sharp
  • Image stabilisation function

Detailed resolution in real time
With a high, detailed resolution of 600 TVL, it delivers precise video images accurate recognition of persons. The analogue picture data is transmitted in real time via a coaxial cable from the camera to a recording system, where it is saved for display.

Automatic focussing for constantly sharp images
The zoom camera detects the distance to an object and automatically adjusts the focus.
With a 36x motorised zoom lens, details are sharp and clear even at great distances.

With soft WDR function and electromechanical IR swivel filter (ICR)
To automatically correct for bright backlight, the camera features the intelligent WDR function,
making it ideal for use in entrance areas. Switching between day and night mode takes place automatically using the integrated IR swivel filter. As well as this, the 1/4“ Sony Exview HAD II CCD image sensor provides detailed images even at night.

Technical data:

Art. no.: TVCC51000
Dimensions: (WxHxD) 60x72x132 mm
Connections: BNC, DC, RS485
Motion detection: yes
Image sensor: 1/4" Sony Exview HAD II CCD
Pixels (effective): 976(H) x 582(V) pixel
Pixels (total): 1028(H) x 596(V) pixel
Width: 60 mm
Focal length: 3,4 - 122,4 mm
Digital zoom: 16 x
DSP: Sony Effio-S
Dynamic range (WDR): 46 dB dB
Electronic shutter: 1/50 s - 1/30000 s
Backlight compensation: DWDR, BLC, HLC
Height: 72 mm
Horizontal angle of view: 1,7 - 57,8 °
Camera outputs: 1 x (1 Vp-p / 75 Ohm)
Camera type: Zoom camera
Length: 132 mm
Max. operating temperature: 50 °C
Max. humidity: 60 %
Min. operating temperature: -10 °C
Minimum illumination (color): 0.1
Minimum illumination (IR): 0
Minimum illumination (B/W): 0.05
Net weight: 0,485 kg
Lens: 3,4 - 122,4 mm
Optical zoom: 36 x
Private zones: Yes
Protocols: PELCO
Noise reduction: DNR
IP protection class: 34
Signal-to-noise ratio: 48
DC voltage supply: 12 V
Language of instructions: DE, UK, FR, NL, DK, PL
OSD language: UK
Control: RS-485
Power consumption: 340 mA
Day/night switching: IR cut can be swivelled electromagnetically
TVL: 600 TVL
Amplifier control: AGC
Video output: FBAS (1 Vss, 75 Ohm)
Video system: PAL
White balance: ATW
Certifications: CE, RoHS, Reach

Scope of delivery:

  • 1x Zoom camera
  • 1x Fixing plate for camera mount
  • 1x User guide
  • 1x Installation material
