HD-SDI repeater
|||||

HD-SDI Repeater (Art. no. TVAC22010)

Special product features:

  • Extends the range of HD-SDI signals
  • Max. range increase: 150 m (RG6 cable), 80 m (RG59 cable)
  • Status LED for signal quality

This HD-SDI repeater is used to extend the transmission distance of HD-SDI signals. The transmission distance can be extended by up to 150 meters (depending on the cable quality).

Technical data:

Art. no.: TVAC22010
Dimensions: 63,6 x 70 x 26 mm
Output: 1 x HD-SDI (SMPTE 259M, SMPTE 292M, SMPTE 494M/495M)
Width: 63.6 mm
Gross weight: 0.4 kg
Data input: 720p50, 720p60, 1080i50, 1080i60, 1080p24, 1080p25, 1080p30, 1080p50, 1080p60, 2K (2048 x 1080)
Input: 1 x HD-SDI (SMPTE 259M, SMPTE 292M, SMPTE 494M/495M)
Height: 26 mm
Length: 70 mm
Max. operating temperature: 50 °C
Max. humidity: 85 %
Min. operating temperature: 0 °C
Net weight: 0.32 kg
DC voltage supply: 6 − 15 V
Language of instructions: DE, UK, FR, NL, DK, PL
Power consumption: 500 mA
Transmission distance: Max. 150 Meter (RG-6), max. 80 Meter (RG-59) m
Certifications: CE

Scope of delivery:

  • 1x User manual
  • 1x Power supply unit including EU, AUS and UK adapters
